Chapt er 2 6 HDMI Input Supported Formats
The Dolby IMS2000 supported frame rate formats provide useful information to help you
verify setup options and avoid performance issues. The Dolby IMS2000 supports HDMI
1.4a and High- bandwidth Digital Content Protection (HDCP) 1.4.
The following table shows the HDMI™ inputs and their supported formats.
Table 26-1 HDMI Inputs: Supported Formats
Interface
Format
Signal Format
Resolution Aspect I/P Color Space
Frame Rate (fps)
23.98 24 25 29.97 30 47.95 48 50 59.94 60
2D
VGA
640 × 480
1.333,
1.778
P
RGB/
component
4:2:2
○ ○
4:4:4
480p
720 × 480
1.333,
1.778
P
RGB/
component
4:2:2
○ ○
4:4:4
576p 720 ×
576
1.333,
1.778
P
RGB/
component
4:2:2
○
4:4:4
HDTV 1280
×
720
1.778 P
RGB/
component
4:2:2
○ ○ ○
4:4:4
HDTV 1920
×
1080
1.778
i/PsF
RGB/
component
4:2:2
○ ○ ○ ○ ○
4:4:4
P
RGB/
component
4:2:2
○ ○ ○ ○ ○ ○ ○ ○ ○ ○
4:4:4
2048 × 1080 1.896
i/PsF
RGB/
component
4.2.2
○ ○ ○ ○ ○
4:4:4
P
RGB/
component
4:2:2
○ ○ ○ ○ ○ ○ ○ ○ ○ ○
4:4:4
3840 × 2160 1.778 P
RGB/
component
4:2:2
○ ○ ○ ○ ○
4:4:4
4096 × 2160 1.896 P
RGB/
component
4:2:2
○ ○
4:4:4
Interface
Format
Signal Format
Resolution Aspect
I/P Color Space Frame Rate (fps)
