4.2 Input and Output Ports
• Three Gigabit Ethernet (RJ-45)
• One eSATA 3 Gbps
• One USB 2.0 port
• Two USB 3.0 ports
• One HDMI input
• Two 3G-SDI bidirectional (input and output)
• Eight AES pair (using two RJ-45)
• Four GPI ports (one RJ-45)
• Six GPO ports (one RJ-45)
4.3 Environmental Specifications
Temperature range (ambient):
• Operating: 10° C to 40° C (50 °F to 104° F)
• Nonoperating: –20° C to 60° C (–4° F to 140° F)
4.4 Performance, Storage, and Power
• The IMS2000 uses three 1 TB hard-disk drives (2.5 inch), providing 2 TB of media
storage.
• Software RAID5 storage.
• The IMS2000 supports up to 4K 30 fps and 2K HFR up to 120 fps.
• The IMS2000 supports 500 Mbps playback.
• Battery: IMS2000 battery is a Panasonic™ vanadium rechargeable lithium battery
(VL3032).
• Power <70 W (power input 12 V @ 6.25 A from projector main low-voltage
differential signaling [LVDS] connector).
• External network-attached storage (NAS) support for additional content storage. (See
Section 12.22.1)
