Dolby
®
IMS2000 Installation and User’s Manual
IMS.OM.004730.DRM Issue 3 249
15.4.1 RAID Information
Storage details lists all the RAIDs configured on the server. Clicking on an individual
RAID will reveal the disks that make up the selected RAID. Clicking on the individual
disks will reveal the information in the unit information portion as well as display a
general visual representation of the RAID:
• An icon to show RAID status (green = healthy; amber = degraded/rebuild; red =
missing)
• Array device name
• Mount point
• Array size
• Array used disk space and free space
• RAID status (healthy, degraded, rebuilding percentage, failed)
• Self-monitoring , analysis, and reporting technology information
• Model and serial number
• A pie chart depicting the percentage of used and free space
15.5 MediaBlock Tab
Click on the MediaBlock button to access it.
The MediaBlock tab is divided into three sections:
• Projector:
• Connection status: Displays the status of the connection with the media block
• Model: Displays the projector model
• Dowser: Displays whether the dowser is open
• Lamp: Displays whether the lamp is on
• Media Decoder:
• Video watermark: Displays the type of watermark present
• Audio watermark: Displays the type of watermark present
• Security Manager:
• Blackout mode
• Service door status
• Service door armed status
• Physical marriage: Displays whether the physical marriage is operational
• Logical marriage: Displays whether the logical marriage is engaged
• Active marriage: Displays whether the active marriage is engaged
