Dolby

IMS2000 Installation and User’s Manual

IMS.OM.004730.DRM Issue 3 21

Figure 5-14 Locking the Projector

4. Reattach the filter cover by pushing it into place.

Figure 5-15 Reattaching the Filter Cover
