B TROUBLESHOOTING
PROBLEMS ACCESSING THE MANAGEMENT INTERFACE
Table 163: Troubleshooting Chart
Symptom Action
Cannot connect using
Telnet, web browser, or
SNMP software
◆ Be sure the switch is powered up.
◆ Check network cabling between the management station
and the switch.
◆ Check that you have a valid network connection to the
switch and that the port you are using has not been
disabled.
◆ Be sure you have configured the VLAN interface through
which the management station is connected with a valid IP
address, subnet mask and default gateway.
◆ Be sure the management station has an IP address in the
same subnet as the switch’s IP interface to which it is
connected.
◆ If you are trying to connect to the switch via the IP
address for a tagged VLAN group, your management
station, and the ports connecting intermediate switches in
the network, must be configured with the appropriate tag.
◆ If you cannot connect using Telnet, you may have
exceeded the maximum number of concurrent Telnet/SSH
sessions permitted. Try connecting again at a later time.
Cannot connect using
Secure Shell
◆ If you cannot connect using SSH, you may have exceeded
the maximum number of concurrent Telnet/SSH sessions
permitted. Try connecting again at a later time.
◆ Be sure the control parameters for the SSH server are
properly configured on the switch, and that the SSH client
software is properly configured on the management
station.
◆ Be sure you have generated both an RSA and DSA public
key on the switch, exported this key to the SSH client, and
enabled SSH service.
◆ Be sure you have set up an account on the switch for each
SSH user, including user name, authentication level, and
password.
◆ Be sure you have imported the client’s public key to the
switch (if public key authentication is used).
Cannot access the on-
board configuration
program via a serial port
connection
◆ Be sure you have set the terminal emulator program to
VT100 compatible, 8 data bits, 1 stop bit, no parity, and the
baud rate set to 115200 bps).
◆ Check that the null-modem serial cable conforms to the pin-
out connections provided in the Installation Guide.
Forgot or lost the
password
◆ Contact your local distributor.
