– 57 –
1 INTRODUCTION
This switch provides a broad range of features for Layer 2 switching and
Layer 3 routing. It includes a management agent that allows you to
configure the features listed in this manual. The default configuration can
be used for most of the features provided by this switch. However, there
are many options that you should configure to maximize the switch’s
performance for your particular network environment.
KEY FEATURES
Table 1: Key Features
Feature Description
Configuration Backup
and Restore
Using management station or FTP/TFTP server
Authentication Console, Telnet, web – user name/password, RADIUS, TACACS+
Web – HTTPS
Tel ne t – SS H
SNMP v1/2c - Community strings
SNMP version 3 – MD5 or SHA password
Port – IEEE 802.1X, MAC address filtering
General Security
Measures
Private VLANs
Port Authentication
Port Security
DHCP Snooping
IP Source Guard
Access Control Lists Supports up to 36 ACLs per port, 93 rules per port
DHCP Client, Relay, Server
DNS Client and Proxy service
Port Configuration Speed and duplex mode and flow control
Port Trunking Supports up to 32 trunks using either static or dynamic trunking
(LACP)
Port Mirroring 24 sessions, one or more source ports to one analysis port
Congestion Control Rate Limiting
Throttling for broadcast storms
Address Table Up to 8K MAC addresses in the forwarding table, 1024 static MAC
addresses;
Up to 4K IPv4 entries in the host table;
4K entries in the ARP cache, 512 static ARP entries;
256 IPv4 entries in the IP routing table, 256 static IP routes, 32 IP
interfaces;
1024 L2 multicast groups
IP Version 4 Supports IPv4 addressing, and management
