C
HAPTER
13
| Security Measures
Configuring 802.1X Port Authentication
– 320 –
DISPLAYING 802.1X
STATISTICS
Use the Security > Port Authentication (Show Statistics) page to display
statistics for dot1x protocol exchanges for any port.
CLI REFERENCES
â—† "show dot1x" on page 702
PARAMETERS
These parameters are displayed in the web interface:
Table 15: 802.1X Statistics
Parameter Description
Rx EAPOL Start The number of EAPOL Start frames that have been received
by this Authenticator.
Rx EAPOL Logoff The number of EAPOL Logoff frames that have been
received by this Authenticator.
Rx EAPOL Invalid The number of EAPOL frames that have been received by
this Authenticator in which the frame type is not
recognized.
Rx EAPOL Total The number of valid EAPOL frames of any type that have
been received by this Authenticator.
Rx Last EAPOLVer The protocol version number carried in the most recent EAPOL
frame received by this Authenticator.
Rx Last EAPOLSrc The source MAC address carried in the most recent EAPOL
frame received by this Authenticator.
Rx EAP Resp/Id The number of EAP Resp/Id frames that have been received
by this Authenticator.
Rx EAP Resp/Oth The number of valid EAP Response frames (other than
Resp/Id frames) that have been received by this
Authenticator.
Rx EAP LenError The number of EAPOL frames that have been received by
this Authenticator in which the Packet Body Length field is
invalid.
Tx EAP Req/Id The number of EAP Req/Id frames that have been
transmitted by this Authenticator.
Tx EAP Req/Oth The number of EAP Request frames (other than Rq/Id
frames) that have been transmitted by this Authenticator.
Tx EAPOL Total The number of EAPOL frames of any type that have been
transmitted by this Authenticator.
