C HAPTER 17 | General IP Routing
Configuring Static Routes
– 447 –
WEB INTERFACE
To display ARP statistics:
1. Click IP, ARP.
2. Select Show Information from the Step List.
3. Click Statistics.
Figure 270: Displaying ARP Statistics
CONFIGURING STATIC ROUTES
This router can dynamically configure routes to other network segments
using dynamic routing protocols (i.e., RIP or OSPF). However, you can also
manually enter static routes in the routing table using the IP > Routing >
Static Routes (Add) page. Static routes may be required to access network
segments where dynamic routing is not supported, or can be set to force
the use of a specific route to a subnet, rather than using dynamic routing.
Static routes do not automatically change in response to changes in
network topology, so you should only configure a small number of stable
routes to ensure network accessibility.
CLI REFERENCES
◆ "ip route" on page 1020
COMMAND USAGE
◆ Up to 512 static routes can be configured.
◆ Up to eight equal-cost multipaths (ECMP) can be configured for static
routing (see "Equal-cost Multipath Routing" on page 450).
◆ If an administrative distance is defined for a static route, and the same
destination can be reached through a dynamic route at a lower
administration distance, then the dynamic route will be used.
◆ If both static and dynamic paths have the same lowest cost, the first
route stored in the routing table, either statically configured or
dynamically learned via a routing protocol, will be used.

Edge-Core ECS4610-24F Specifications

General

Model	ECS4610-24F
Switching Capacity	128 Gbps
MAC Address Table Size	16K
Jumbo Frames	9K Bytes
Operating Humidity	10% to 90% (non-condensing)
Storage Humidity	5% to 95% (non-condensing)
Layer	L2/L3
Forwarding Rate	95.2 Mpps
VLANs	4K
Management	Web, CLI, SNMP
Power Supply	Internal
Dimensions (W x D x H)	440 x 44 x mm
Operating Temperature	0°C
Storage Temperature	-40°C to 70°C
Ports	24 x 1G SFP ports, 4 x 10G SFP+ ports
