Page #838 background image
C
HAPTER
36
| VLAN Commands
Configuring VLAN Interfaces
– 838 –
DEFAULT SETTING
By default only VLAN 1 exists and is active.
COMMAND MODE
VLAN Database Configuration
COMMAND USAGE
no vlan vlan-id deletes the VLAN.
no vlan vlan-id name removes the VLAN name.
no vlan vlan-id state returns the VLAN to the default state
(i.e., active).
You can configure up to 4093 VLANs on the switch.
EXAMPLE
The following example adds a VLAN, using VLAN ID 105 and name RD5.
The VLAN is activated by default.
Console(config)#vlan database
Console(config-vlan)#vlan 105 name RD5 media ethernet
Console(config-vlan)#
RELATED COMMANDS
show vlan (845)
CONFIGURING VLAN INTERFACES
Table 96: Commands for Configuring VLAN Interfaces
Command Function Mode
interface vlan Enters interface configuration mode for a specified
VLAN
GC
switchport acceptable-
frame-types
Configures frame types to be accepted by an
interface
IC
switchport allowed vlan Configures the VLANs associated with an interface IC
switchport forbidden vlan Configures forbidden VLANs for an interface IC
switchport gvrp Enables GVRP for an interface IC
switchport ingress-
filtering
Enables ingress filtering on an interface IC
switchport mode Configures VLAN membership mode for an interface IC
switchport native vlan Configures the PVID (native VLAN) of an interface IC
switchport priority default Sets a port priority for incoming untagged frames IC
vlan-trunking Allows unknown VLANs to cross the switch IC
