C
HAPTER
5
| Interface Configuration
Port Configuration
– 130 –
CONFIGURING PORT
MIRRORING
Use the Interface > Port > Mirror page to mirror traffic from any source
port to a target port for real-time analysis. You can then attach a logic
analyzer or RMON probe to the target port and study the traffic crossing
the source port in a completely unobtrusive manner.
Figure 26: Configuring Local Port Mirroring
CLI REFERENCES
â—† "Local Port Mirroring Commands" on page 797
COMMAND USAGE
â—† Traffic can be mirrored from one or more source ports to one
destination port on the same switch.
â—† Monitor port speed should match or exceed source port speed,
otherwise traffic may be dropped from the monitor port.
â—† When mirroring port traffic, the target port must be included in the
same VLAN as the source port when using MSTP (see "Spanning Tree
Algorithm" on page 195).
PARAMETERS
These parameters are displayed in the web interface:
◆ Source Port – The port whose traffic will be monitored. (Range: 1-24)
◆ Target Port – The port that will mirror the traffic on the source port.
(Range: 1-24)
◆ Type – Allows you to select which traffic to mirror to the target port, Rx
(receive), Tx (transmit), or Both. (Default: Rx)
WEB INTERFACE
To configure a local mirror session:
1. Click Interface, Port, Mirror.
2. Select Add from the Action List.
3. Specify the source port.
4. Specify the monitor port.
5. Specify the traffic type to be mirrored.
6. Click Apply.
Source
port(s)
Single
target
port
