C
HAPTER
38
| Quality of Service Commands
– 888 –
match This command defines the criteria used to classify traffic. Use the no form
to delete the matching criteria.
SYNTAX
[no] match {access-list acl-name | ip dscp dscp |
ip precedence ip-precedence | ipv6 dscp dscp | vlan vlan}
acl-name - Name of the access control list. Any type of ACL can be
specified, including standard or extended IP ACLs and MAC ACLs.
(Range: 1-16 characters)
dscp - A Differentiated Service Code Point value. (Range: 0-63)
ip-precedence - An IP Precedence value. (Range: 0-7)
vlan - A VLAN. (Range:1-4093)
DEFAULT SETTING
None
COMMAND MODE
Class Map Configuration
COMMAND USAGE
◆ First enter the class-map command to designate a class map and enter
the Class Map configuration mode. Then use match commands to
specify the fields within ingress packets that must match to qualify for
this class map.
◆ If an ingress packet matches an ACL specified by this command, any
deny rules included in the ACL will be ignored.
◆ If match criteria includes an IP ACL or IP priority rule, then a VLAN rule
cannot be included in the same class map.
◆ If match criteria includes a MAC ACL or VLAN rule, then neither an IP
ACL nor IP priority rule can be included in the same class map.
◆ Up to 16 match entries can be included in a class map.
EXAMPLE
This example creates a class map called “rd-class#1,” and sets it to match
packets marked for DSCP service value 3.
Console(config)#class-map rd-class#1 match-any
Console(config-cmap)#match ip dscp 3
Console(config-cmap)#
