C
HAPTER
40
| LLDP Commands
– 963 –
â—† SNMP trap destinations are defined using the snmp-server host
command.
â—† Information about additional changes in LLDP neighbors that occur
between SNMP notifications is not transmitted. Only state changes that
exist at the time of a trap notification are included in the transmission.
An SNMP agent should therefore periodically check the value of
lldpStatsRemTableLastChangeTime to detect any lldpRemTablesChange
notification-events missed due to throttling or transmission loss.
EXAMPLE
Console(config)#interface ethernet 1/1
Console(config-if)#lldp notification
Console(config-if)#
show lldp config This command shows LLDP configuration settings for all ports.
SYNTAX
show lldp config [detail interface]
detail - Shows configuration summary.
interface
ethernet unit/port
unit - Stack unit. (Range: 1)
port - Port number. (Range: 1-24)
port-channel channel-id (Range: 1-32)
COMMAND MODE
Privileged Exec
EXAMPLE
Console#show lldp config
LLDP Global Configuation
LLDP Enable : Yes
LLDP Transmit interval : 30
LLDP Hold Time Multiplier : 4
LLDP Delay Interval : 2
LLDP Reinit Delay : 2
LLDP Notification Interval : 5
LLDP MED fast start counts : 4
LLDP Port Configuration
Interface |AdminStatus NotificationEnabled
--------- + ----------- -------------------
Eth 1/1 | Tx-Rx True
Eth 1/2 | Tx-Rx True
Eth 1/3 | Tx-Rx True
Eth 1/4 | Tx-Rx True
