Page #772 background image
C
HAPTER
30
| Interface Commands
– 772 –
EXAMPLE
The following example configures Ethernet port 5 capabilities to include
100half and 100full.
Console(config)#interface ethernet 1/5
Console(config-if)#capabilities 100half
Console(config-if)#capabilities 100full
Console(config-if)#capabilities flowcontrol
Console(config-if)#
RELATED COMMANDS
negotiation (774)
speed-duplex (776)
flowcontrol (773)
description This command adds a description to an interface. Use the no form to
remove the description.
SYNTAX
description string
no description
string - Comment or a description to help you remember what is
attached to this interface. (Range: 1-64 characters)
DEFAULT SETTING
None
COMMAND MODE
Interface Configuration (Ethernet, Port Channel)
COMMAND USAGE
The description is displayed by the show interfaces status command and in
the running-configuration file. An example of the value which a network
manager might store in this object is the name of the manufacturer, and
the product name.
EXAMPLE
The following example adds a description to port 4.
Console(config)#interface ethernet 1/4
Console(config-if)#description RD-SW#3
Console(config-if)#
