C
HAPTER
36
| VLAN Commands
Configuring IEEE 802.1Q Tunneling
– 849 –
COMMAND USAGE
â—† Use the switchport dot1q-tunnel tpid command to set a custom
802.1Q ethertype value on the selected interface. This feature allows
the switch to interoperate with third-party switches that do not use the
standard 0x8100 ethertype to identify 802.1Q-tagged frames. For
example, 0x1234 is set as the custom 802.1Q ethertype on a trunk
port, incoming frames containing that ethertype are assigned to the
VLAN contained in the tag following the ethertype field, as they would
be with a standard 802.1Q trunk. Frames arriving on the port
containing any other ethertype are looked upon as untagged frames,
and assigned to the native VLAN of that port.
â—† All ports on the switch will be set to the same ethertype.
EXAMPLE
Console(config)#interface ethernet 1/1
Console(config-if)#switchport dot1q-tunnel tpid 9100
Console(config-if)#
RELATED COMMANDS
show interfaces switchport (781)
show dot1q-tunnel This command displays information about QinQ tunnel ports.
COMMAND MODE
Privileged Exec
EXAMPLE
Console(config)#dot1q-tunnel system-tunnel-control
Console(config)#interface ethernet 1/1
Console(config-if)#switchport dot1q-tunnel mode access
Console(config-if)#interface ethernet 1/2
Console(config-if)#switchport dot1q-tunnel mode uplink
Console(config-if)#end
Console#show dot1q-tunnel
Current double-tagged status of the system is Enabled
The dot1q-tunnel mode of the set interface 1/1 is Access mode, TPID is 0x8100.
The dot1q-tunnel mode of the set interface 1/2 is Uplink mode, TPID is 0x8100.
The dot1q-tunnel mode of the set interface 1/3 is Normal mode, TPID is 0x8100.
.
.
.
RELATED COMMANDS
switchport dot1q-tunnel mode (847)
