– 125 –
5 INTERFACE CONFIGURATION
This chapter describes the following topics:
◆ Port Configuration – Configures connection settings, including auto-
negotiation, or manual setting of speed, duplex mode, and flow control.
◆ Port Mirroring – Sets the source and target ports for mirroring on the
local switch.
◆ Displaying Statistics – Shows Interface, Etherlike, and RMON port
statistics in table or chart form.
◆ Trunk Configuration – Configures static or dynamic trunks.
◆ Traffic Segmentation – Configures the uplinks and down links to a
segmented group of ports.
◆ VLAN Trunking – Configures a tunnel across one or more intermediate
switches which pass traffic for VLAN groups to which they do not
belong.
PORT CONFIGURATION
This section describes how to configure port connections, mirror traffic
from one port to another, and run cable diagnostics.
CONFIGURING BY
PORT LIST
Use the Interface > Port > General (Configure by Port List) page to enable/
disable an interface, set auto-negotiation and the interface capabilities to
advertise, or manually fix the speed, duplex mode, and flow control.
CLI REFERENCES
â—† "Interface Commands" on page 769
COMMAND USAGE
â—† Auto-negotiation must be disabled before you can configure or force a
Gigabit Ethernet interface to use the Speed/Duplex mode or Flow
Control options.
â—† When using auto-negotiation, the optimal settings will be negotiated
between the link partners based on their advertised capabilities. To set
the speed, duplex mode, or flow control under auto-negotiation, the
required operation modes must be specified in the capabilities list for
an interface.
