C
HAPTER
17
| General IP Routing
Address Resolution Protocol
– 445 –
Figure 266: Configuring Static ARP Entries
To display static entries in the ARP cache:
1. Click IP, ARP.
2. Select Configure Static Address from the Step List.
3. Select Show from the Action List.
Figure 267: Displaying Static ARP Entries
DISPLAYING DYNAMIC
OR LOCAL ARP
ENTRIES
The ARP cache contains static entries, and entries for local interfaces,
including subnet, host, and broadcast addresses. However, most entries will
be dynamically learned through replies to broadcast
messages. Use the IP >
ARP (Show Information) page to display dynamic or local entries in the ARP
cache
.
CLI REFERENCES
â—† "show arp" on page 1014
WEB INTERFACE
To display all dynamic entries in the ARP cache:
1. Click IP, ARP.
2. Select Show Information from the Step List.
3. Click Dynamic Address.
