C
HAPTER
19
| IP Services
Dynamic Host Configuration Protocol
– 471 –
Figure 294: Configuring DHCP Relay Service
CONFIGURING THE
DHCP SERVER
This switch includes a Dynamic Host Configuration Protocol (DHCP) server
that can assign temporary IP addresses to any attached host requesting
service. It can also provide other network settings such as the domain
name, default gateway, Domain Name Servers (DNS), Windows Internet
Naming Service (WINS) name servers, or information on the bootup file for
the host device to download.
Addresses can be assigned to clients from a common address pool
configured for a specific IP interface on this switch, or fixed addresses can
be assigned to hosts based on the client identifier code or MAC address.
Figure 295: DHCP Server
COMMAND USAGE
â—† First configure any excluded addresses, including the address for this
switch.
â—† Then configure address pools for the network interfaces. You can
configure up to 8 network address pools. You can also manually bind an
address to a specific client if required. However, any fixed addresses
must fall within the range of an existing network address pool. You can
configure up to 32 fixed host addresses (i.e., entering one address per
pool).
â—† If the DHCP server is running, you must disable it and then reenable it
to implement any configuration changes. This can be done on the IP
Service > DHCP > Server (Configure Global) page.
ENABLING THE SERVER
Use the IP Service > DHCP > Server (Configure Global) page to enable the
DHCP Server.
8 network
address pools
Address
Pool
Static
Addresses
32 static addresses
(all within the confines
of configured network
address pools)
To Next Page
