C
HAPTER
5
| Interface Configuration
Port Configuration
– 127 –
operation and IEEE 802.3-2005 (formally IEEE 802.3x) for full-
duplex operation.
Avoid using flow control on a port connected to a hub unless it is
actually required to solve a problem. Otherwise back pressure
jamming signals may degrade overall performance for the segment
attached to the hub.
(Default: Autonegotiation enabled on Gigabit ports, disabled on 10G
ports; Advertised capabilities for
1000BASE-T – 10half, 10full, 100half, 100full, 1000full;
1000Base-SX/LX/LH – 1000full)
◆ Speed/Duplex – Allows you to manually set the port speed and
duplex mode. (i.e., with auto-negotiation disabled)
◆ Flow Control – Allows automatic or manual selection of flow control.
WEB INTERFACE
To configure port connection parameters:
1. Click Interface, Port, General.
2. Select Configure by Port List from the Action List.
3. Modify the required interface settings.
4. Click Apply.
Figure 23: Configuring Connections by Port List
