C
HAPTER
5
| Interface Configuration
Trunk Configuration
– 146 –
WEB INTERFACE
To display LACP settings and status for the local side:
1. Click Interface, Trunk, Dynamic.
2. Select Configure Aggregation Port from the Step list.
3. Select Show Information from the Action list.
4. Click Internal.
5. Select a group member from the Port list.
Admin State,
Oper State
Administrative or operational values of the actor’s state parameters:
â—†
Expired – The actor’s receive machine is in the expired state;
â—†
Defaulted – The actor’s receive machine is using defaulted
operational partner information, administratively configured
for the partner.
â—†
Distributing – If false, distribution of outgoing frames on this
link is disabled; i.e., distribution is currently disabled and is not
expected to be enabled in the absence of administrative
changes or changes in received protocol information.
â—†
Collecting – Collection of incoming frames on this link is
enabled; i.e., collection is currently enabled and is not
expected to be disabled in the absence of administrative
changes or changes in received protocol information.
â—†
Synchronization – The System considers this link to be
IN_SYNC; i.e., it has been allocated to the correct Link
Aggregation Group, the group has been associated with a
compatible Aggregator, and the identity of the Link
Aggregation Group is consistent with the System ID and
operational Key information transmitted.
â—†
Aggregation – The system considers this link to be
aggregatable; i.e., a potential candidate for aggregation.
â—†
Long timeout – Periodic transmission of LACPDUs uses a slow
transmission rate.
â—†
LACP-Activity – Activity control value with regard to this link.
(0:Passive;1:Active)
Table 7: LACP Internal Configuration Information (Continued)
Parameter Description
