C
HAPTER
5
| Interface Configuration
VLAN Trunking
– 152 –
PARAMETERS
These parameters are displayed in the web interface:
◆ Interface – Displays a list of ports or trunks.
◆ Port – Port Identifier. (Range: 1-24)
N
OTE
:
VLAN trunking can only be enabled on Gigabit ports.
◆ Trunk – Trunk Identifier. (Range: 1-32)
◆ VLAN Trunking Status – Enables VLAN trunking on the selected
interface.
WEB INTERFACE
To enable VLAN trunking on a port or trunk:
1. Click Interface, VLAN Trunking.
2. Click Port or Trunk to specify the interface type.
3. Enable VLAN trunking on any of the Gigibit ports or on a trunk
containing Gigabit ports.
4. Click Apply.
Figure 49: Configuring VLAN Trunking
