Edge-Core ECS4610-24F User Manual

C HAPTER 6 | VLAN Configuration
Protocol VLANs
– 181 –
6. Enter the corresponding VLAN to which the protocol traffic will be
forwarded.
7. Click Apply.
Figure 72: Assigning Interfaces to Protocol VLANs
To show the protocol groups mapped to a port or trunk:
1. Click VLAN, Protocol.
2. Select Configure Interface from the Step list.
3. Select Show from the Action list.
Figure 73: Showing the Interface to Protocol Group Mapping
