C HAPTER 14 | Basic Administration Protocols
Remote Monitoring
– 383 –
◆ Owner - Name of the person who created this entry. (Range: 1-127
characters)
WEB INTERFACE
To periodically sample statistics on a port:
1. Click Administration, RMON.
2. Select Configure Interface from the Step list.
3. Select Add from the Action list.
4. Click History.
5. Select a port from the list as the data source.
6. Enter an index number, the sampling interval, the number of buckets to
use, and the name of the owner for this entry.
7. Click Apply
Figure 219: Configuring an RMON History Sample
To show configured RMON history samples:
1. Click Administration, RMON.
2. Select Configure Interface from the Step list.
3. Select Show from the Action list.
4. Select a port from the list.
5. Click History.
