C
HAPTER
32
| Port Mirroring Commands
Local Port Mirroring Commands
– 799 –
COMMAND USAGE
This command displays the currently configured source port, destination
port, and mirror mode (i.e., RX, TX, RX/TX).
EXAMPLE
The following shows mirroring configured from port 6 to port 11:
Console(config)#interface ethernet 1/11
Console(config-if)#port monitor ethernet 1/6
Console(config-if)#end
Console#show port monitor
Port Mirroring
-------------------------------------
Destination Port (listen port): Eth1/1
Source Port (monitored port): Eth1/6
Mode :RX/TX
Console#
