C
HAPTER
3
| Using the Web Interface
Navigating the Web Browser Interface
– 85 –
Trunk
Static
Configure Trunk
Add Creates a trunk, along with the first port member 136
Show Shows the configured trunk identifiers 136
Add Member Specifies ports to group into static trunks 136
Show Member Shows the port members for the selected trunk 136
Configure General
Configure Configures trunk connection settings 136
Show Information Displays trunk connection settings 136
Dynamic 139
Configure Aggregator Configures administration key for specific LACP groups 139
Configure Aggregation Port
Configure
General Allows ports to dynamically join trunks 139
Actor Configures parameters for link aggregation group members on the
local side
139
Partner Configures parameters for link aggregation group members on the
remote side
139
Show Information
Counters Displays statistics for LACP protocol messages 144
Internal Displays configuration settings and operational state for the local
side of a link aggregation
145
Neighbors Displays configuration settings and operational state for the
remote side of a link aggregation
147
Configure Trunk
Configure Configures connection settings 139
Show Displays port connection status 139
Show Member Shows the active members in a trunk 139
Statistics Shows Interface, Etherlike, RMON and Utilization trunk statistics 131
Chart Shows Interface, Etherlike, RMON and Utilization trunk statistics 131
Traffic Segmentation
Configure Global Enables traffic segmentation globally 149
Configure Session Configures the uplink and down-link ports for a segmented group
of ports
150
VLAN Trunking Allows unknown VLAN groups to pass through the specified
interface
151
Table 4: Switch Main Menu (Continued)
Menu Description Page
