C
HAPTER
3
| Using the Web Interface
Navigating the Web Browser Interface
– 93 –
Show Details
History Shows sampled data for each entry in the history group 382
Statistics Shows sampled data for each entry in the history group 384
IP
General
Routing Interface
Add Configures an IP interface for a VLAN 431
Show Shows the IP interfaces assigned to a VLAN 431
Ping Sends ICMP echo request packets to another node on the network 439
Trace Route Shows the route packets take to the specified
destination
440
ARP Address Resolution Protocol 441
Configure General Sets the protocol timeout, and enables or disables
proxy ARP for the specified VLAN
442
Configure Static Address 444
Add Statically maps a physical address to an IP address 444
Show Shows the MAC to IP address static table 444
Show Information
Dynamic Address Shows dynamically learned entries in the IP routing table 445
Other Address Shows internal addresses used by the switch 445
Statistics Shows statistics on ARP requests sent and received 446
Routing
Static Routes 447
Add Configures static routing entries 447
Show Shows static routing entries 447
Modify Modifies the selected static routing entry 447
Routing Table
Show Information Shows all routing entries, including local, static and dynamic
routes
449
Configure ECMP Number Sets the maximum number of equal-cost paths to the same
destination that can be installed in the routing table
450
VRRP Virtual Router Redundancy Protocol 453
Configure Group ID 454
Add Adds a VRRP group identifier to a VLAN 454
Show Shows the VRRP group identifier list 454
Add IP Address Sets a virtual interface address for a VRRP group 454
Show IP Addresses Shows the virtual interface address assigned to a VRRP group 454
Table 4: Switch Main Menu (Continued)
Menu Description Page
