Fuji Xerox DocuPrint CM305 df Service Manual

2 - 177
Chapter 2 Troubleshooting
21
Checking the DRIVE ASSY MAIN for installation.
Reseat the DRIVE ASSY MAIN.
Does the noise arise from the printer?
Checked by [Digital Output] - [Main Motor] in [IOT Diag] of
diagnosis.
Try replacing the
PHD ASSY (Refer
to REP4.6.), KIT
TRANSFER
ASSY (Refer to
REP6.3.) and KIT
DRIVE ASSY
MAIN (Refer to
REP7.2.) one after
another.
End of work.
22
Checking the Sub Motor.
Does the noise arise from the printer?
Checked by [Digital Output] - [Sub Motor] in [IOT Diag] of
diagnosis.
Go to step 23.
Check the
installation
situation of the
printer.
23
Checking the PHD ASSY for installation.
Reseat the PHD ASSY.
Does the noise arise from the printer?
Checked by [Digital Output] - [Sub Motor] in [IOT Diag] of
diagnosis.
Go to step 24. End of work.
24
Checking the FUSING UNIT for installation.
Reseat the FUSING UNIT.
Does the noise arise from the printer?
Checked by [Digital Output] - [Sub Motor] in [IOT Diag] of
diagnosis.
Go to step 25. End of work.
25
Checking the DRIVE ASSY SUB for installation.
Reseat the DRIVE ASSY SUB.
Does the noise arise from the printer?
Checked by [Digital Output] - [Sub Motor] in [IOT Diag] of
diagnosis.
Try replacing the
PHD ASSY (Refer
to REP4.6.),
FUSING UNIT
(Refer to REP6.1.)
after replacement,
be sure to clear
the life counter
value, and DRIVE
ASSY SUB (Refer
to REP7.1.) one
after another.
End of work.
Step Check
Remedy
Yes No
