4 - 71
Chapter 4 Disassembly / Assembly and Adjustments
12) Open the COVER ASSY FRONT.
11) Remove the ROLL ASSY FEED
from the SHAFT ASSY FEED by
rotating the ROLL ASSY FEED 180
degrees.
13) Remove the SPRING FEED OUT
(PL3.1.15) from the printer.
