4 - 135
Chapter 4 Disassembly / Assembly and Adjustments
9) Remove the SPRING PHD (PL4.1.4)
from the printer.
10) Rotate the LEVER PHD (PL4.1.5)
slightly, remove the LEVER PHD
from the printer.
