4 - 136
Chapter 4 Disassembly / Assembly and Adjustments
[Replacement]
Described below is the replacement procedure common among the upper and
lower of the BLOCK STOPPER PHD ADs.
1) Tilt the LEVER PHD slightly,
attach the LEVER PHD to the
printer.
2) Attach the SPRING PHD to the
printer.
3) Push the BLOCK STOPPER PHD
AD to the printer until it is locked.
To Next Page
