4 - 191
Chapter 4 Disassembly / A
ssembly and Adjustments
10)
Remove the one screw
(silver, M4,
6mm) and the five screws (silver,
tap, 8mm) that fix the DRIVE ASSY
MAIN to the printer.
11)
Remove the DRIVE ASSY MAIN
from the printer.
