4 - 227
Chapter 4 Disassembly / Assembly and Adjustments
25) Remove the one screw (silver, M4,
6mm) that fixes the inside of the
PLATE ASSY TOP to the printer.
26) Remove the PLATE ASSY TOP from
the printer.
