4 - 287
Chapter 4 Disassembly / Assembly and Adjustments
3) Mate the two holes of the
BRACKET ASSY USB with the two
bosses of the IIT ASSY SUB, secure
the BRACKET ASSY USB with the
one screw (silver, tap, 8mm)and the
one screw (silver, 6mm).
4) Engage the connecter (P/J2) of the
PWB ASSY FRONT USB.
