Fuji Xerox DocuPrint CM305 df Service Manual

4 - 294
Chapter 4 Disassembly / Assembly and Adjustments
[Replacement]
1) Attach the ROLLER ASSY DUP to
the FEEDER ASSY DUP AIO STD.
2) Replace the BEARING DUP on both
the right and left sides of the
ROLLER ASSY DUP by matching
the tab of the BEARING DUP with
the notch of the FEEDER ASSY
DUP AIO STD.
Clamp the BEARING DUP firmly to
the FEEDER ASSY DUP AIO STD.
