Fuji Xerox DocuPrint CM305 df Service Manual

6 – 58
Chapter 6 General
825-648
Instructions 1 on Enable Bit
Speed
G3M_V34_BIT_RATE_ENABLE1
0x00
～ 0xFF
0x01: 2400bps
0x02: 4800bps
0x04: 7200bps
0x08: 9600bps
0x10: 12000bps
0x20: 14400bps
0x40: 16800bps
0x80: 19200bps
0xFF CE
825-649
Instructions 2 on Enable Bit
Speed
G3M_V34_BIT_RATE_ENABLE2
0x00
～ 0x3F
0x01: 21600bps
0x02: 24000bps
0x04: 26400bps
0x08: 28800bps
0x10: 31200bps
0x20: 33600bps
0x3F CE
825-650 Control Channel Bit Speed G3M_V34_CTRL_BIT_RATE
0:1200bps
1:2400bps
0CE
825-653 Bit Speed Selection: Threshold
G3M_V34_BIT_RATE_THRESHOL
D
0x00
～ 0xFF
0x09 CE
825-655 V8Te Time G3M_V8_TE_TIME
0
～ 255:0 ～ 25.5S
100ms/step
11 CE
825-656
Timeout time from V34 mode
(Phase2) to Control Channel
G3M_V34_CC_TIMER
5
～ 255: 5 to 255 sec
1sec/step
30 CE
825-657
Set whether to move to G3
mode at V34_CC_TIMER
timeout.
G3M_V34_SHIFT_G3
0: Prohibit
1: Permit
1CE
825-658 V34 Capacity CAPAB_V34
0: Not capable
1: Capable
1 V.34 Capacity setting CE
825-659
ANSam Signal: max sending
time
ANSAM_SEND_TIME
1
～ 255:0.1s ～ 25.5s
40 100ms/step CE
825-660
Time from line connection to
ANSam Signal sending out
(An increase of approx. 1.3 sec
from a setting value due to
modem restrictions)
ANSAM_START_TIME
22
～ 255:2.2s ～ 25.5s
22 100ms/step CE
825-661 Encoding method at send G3M_TX_CODING
0:MH
1:MR
2:MMR
3:JBIG
3CE
825-662 Encoding method at receive G3M_RX_CODING
0:MH
1:MR
2:MMR
3:JBIG
3CE
825-664 Receive Gain Correction Value RX_GAIN_ADJUSTMENT
-128
～ 127
(0.75dB/step)
1 Shifts a range of receive levels. CE
825-665 V34 1 Frame Size G3M_V34_FRAME_SIZE
0:256octets
1:64octets
0CE
825-666 Sending of Manual Send CNG MANUAL_CNG_SIGNAL
0: Not send
1: Send
1CE
825-667 Tone Sending Level TONE_TX_ATT
0
～ 15:0dBm ～ -15dBm
10 Sending Level setting CE
825-668 Incoming Call Level RX_ATT
0:-43dBm
1:-33dBm
2:-21dBm
3:-16dBm
0 Incoming Call Level setting CE
825-669 Storage of Decode Error Pages SAVE_ERROR_RX_DATA
0: Not store
1: Store
1CE
825-673 LRLTWO (ref. line) Value DFAULT_JBIG_LRLTWO
0: 3 lines
1: 2 lines
0CE
Chain
-Link
Description Name Value Label
Default Details Access
OFF/
ON
