Fuji Xerox DocuPrint CM305 df Service Manual

6 – 59
Chapter 6 General
825-701
Fax Commu. Speed Setting for
display on panel
UI_FAX_SPEED
0:2400,
1:4800,
2:9600,
3:14400,
4:33600
4
Change the 3 pieces of system
data simultaneously.
2400:
CAPAB_V34=Not capable
G3M_TX_MODEM_SPEED=1
G3M_RX_MODEM_SPEED=1
4800:
CAPAB_V34=Not capable
G3M_TX_MODEM_SPEED=2
G3M_RX_MODEM_SPEED=2
9600:
CAPAB_V34=Not capable
G3M_TX_MODEM_SPEED=3
G3M_RX_MODEM_SPEED=4
14400:
CAPAB_V34=Not capable
G3M_TX_MODEM_SPEED=5
G3
USER
825-702
Threshold 0 for detection of
External Tel Hook Status
EXTEL_HOOK_THRESH_0
0
～ 255V
6
When
ONHOOK_LVS_THRESH_HI
is "
０ ", this setting is used as
External Tel Hook Status
Detection Threshold.
If a faulty detection of an Ext.
Tel Hook status occurs despite a
change of
ONHOOK_LVS_THRESH_HI,
change either
EXTEL_HOOK_THRESH_0 or
2 for action. At this time, decide
a voltage change to be used as a
threshold, using an actual value
measured on a defective line.
CE
825-703
Threshold 1 for detection of
External Tel Hook Status
EXTEL_HOOK_THRESH_1
0
～ 255V
10
When
ONHOOK_LVS_THRESH_HI
is "1", this setting is used as Ext.
Tel Hook Status Detection
Threshold.
If a faulty detection of an Ext.
Tel Hook status occurs despite a
change of
ONHOOK_LVS_THRESH_HI,
change either
EXTEL_HOOK_THRESH_0 or
2 for action. At this time, decide
a voltage change to be used as a
threshold, using an actual value
measured on a defective line.
CE
825-704
Threshold 2 for detection of
External Tel Hook Status
EXTEL_HOOK_THRESH_2
0
～ 255V
20
When
ONHOOK_LVS_THRESH_HI
is "2", this setting is used as Ext.
Tel Hook Status Detection
Threshold.
If a faulty detection of an Ext.
Tel Hook status occurs despite a
change of
ONHOOK_LVS_THRESH_HI,
change either
EXTEL_HOOK_THRESH_0 or
2 for action. At this time, decide
a voltage change to be used as a
threshold, using an actual value
measured on a defective line.
CE
825-705
Supp. process of detecting the
status of ETSI Standard Ext. Tel
Hook
CAPAB_EXTEL_HOOK_SUPPLEM
ENT
0: Disable
1: Enable
0
Enable/disable starting the supp.
process for Ext. Tel.
CE
825-706
Supp. process for detecting the
status of ETSI Stan. Ext. Tel
Hook
EXTEL_HOOK_SUPPLEMNT_VOL
THRESH
10,15,20(V) 15
Supp. Process for Ext. Tel:
Voltage Value by which to
decide Ext. Tel is off hook
CE
950-001 FORGET_ERROR_secret CE
950-002 CODE_CHECK_secret CE
950-003 PMQAT_BOARD_secret CE
950-004 DONT_DEL_TXFILE 0 CE
950-005 DONT_PR_RCVFILE 0 CE
Chain
-Link
Description Name Value Label
Default Details Access
OFF/
ON
