6 – 57
Chapter 6 General
825-631 Receive Cable Equalizer G3M_RX_CABLE_EQU
0:0db(0km)
1:4db(1.9km)
2:8db(3.6km)
3:12db(7.2km)
4:Complex=for 1
0
If the value of
"DAA_REG731:Complex" is
"1", it is necessary to set
"G3M_RX_CABLE_EQU=4"
to satisfy communication
performance. (When setting this
Chain-Link, see the current
DAA_REG731value set for
each country. Take care in order
to add a line and a row
properly.)
CE
825-632 TAP HOLD G3M_TAP_HOLD
0:OFF
1:Do TAP Hold
0CE
825-633 EP Tone G3M_V29_EPT
0: Not give
1: Give
0CE
825-634 DIS/DTC FIF Send Byte Qty EXTENDED_DIS_DTC
0:4Byte system
1:5Byte system
2:6Byte system
3:7Byte system
4:8Byte system
5:9Byte system
6:10Byte system
7:11Byte system
8:12Byte system
9:13Byte system
10:14Byte system (max
capacity)
10 CE
825-635 ECM Capacity CAPAB_ECM
0: Not capable
1: Capable
1CE
825-636 ECM/CTC Send Qty G3M_CTC_NO
0
~
7: 0 to 7
5CE
825-637 RNR Signal Timer G3M_T5_TIMER
0
~
255:0s
~
255s
65 1S/step CE
825-638
4800bps EQM Comparative
Va l u e
G3M_EQM_48
0x00
~
0x7F
0x0D CE
825-639
7200bps EQM Comparative
Va l u e
G3M_EQM_72
0x00
~
0x7F
0x10 CE
825-640
9600bps EQM Comparative
Va l u e
G3M_EQM_96
0x00
~
0x7F
0x07 CE
825-641
12000bps EQM Comparative
Va l u e
G3M_EQM_120
0x00
~
0x7F
0x1c CE
825-642
14400bps EQM Comparative
Va l u e
G3M_EQM_144
0x00
~
0x7F
0x24 CE
825-643
TCM7200bps EQM
Comparative Value
G3M_EQM_TCM72
0x00
~
0x7F
0x16 CE
825-644
TCM9600bps EQM
Comparative Value
G3M_EQM_TCM96
0x00
~
0x7F
0x22 CE
825-645
Symbol Speed: max allowance
(effective at receive only)
G3M_V34_MAX_SYMBOL_RATE
0:2400baund
1:2743baund
(unsupported)
2:2800baund
3:3000baund
4:3200baund
5:3429baund
5CE
825-646 Bit Speed: max value G3M_V34_MAX_BIT_RATE
1:2400bps
2:4800bps
3:7200bps
4:9600bps
5:12000bps
6:14400bps
7:16800bps
8:19200bps
9:21600bps
10:24000bps
11:26400bps
12:28800bps
13:31200bps
14:33600bps
14 CE
825-647
Instructions on Enable Symbol
Speed
G3M_V34_SYM_RATE_ENABLE1
0x00
~
0x3D
0x01:2400baund
0x02:2743baund
(unsupported)
0x04:2800baund
0x08:3000baund
0x10:3200baund
0x20
:
3429baund
0x3D CE
Chain
-Link
Description Name Value Label
Default
Details Access
OFF/
ON
