Fuji Xerox DocuPrint CM305 df Service Manual

6 – 56
Chapter 6 General
825-605
Selection of criteria for
stopping sending CNG
CNG_STOP_SELECT
0,1,2
0: CED & V.21 Preamble
detected
1: CED detected
2: V21 Preamble detected
0USER
825-608
Criterion (rate) for sending RTN
Command
RTN_TX_RATE
0
～ 100:0% ～ 100%
51%/step CE
825-609
Criterion (continuous-line qty)
for sending RTN Command
RTN_TX_LINE
0
～ 255:0line ～ 255line
5 1line/step CE
825-610
T1 Timer Value right after call-
out
G3M_CALL_T1_TIMER
0
～ 255:0s ～ 255s
50 1S/step CE
825-611 T1 Timer Value at send G3M_TX_T1_TIMER
0
～ 255:0s ～ 255s
36 1S/step CE
825-612 T1 Timer Value at receive G3M_RX_T1_TIMER
0
～ 255:0s ～ 255s
39 1S/step CE
825-613 T2 Timer Value G3M_T2_TIMER
0
～ 255:0s ～ 25.5s
60 100ms/step CE
825-614 T3 Timer Value G3M_T3_TIMER
0
～ 255:0s ～ 25.5s
150 100ms/step CE
825-615
Auto Send/Receive T4 Timer
Va l u e
G3M_AUTO_T4_TIMER
0
～ 255:0s ～ 25.5s
30 100ms/step CE
825-616
Manual Send/Receive T4 Timer
Va l u e
G3M_MAN_T4_TIMER
0
～ 255:0s ～ 25.5s
45 100ms/step CE
825-617 No-sound Time Timer Value G3M_IVL_TIMER
0
～ 255:0ms ～ 255ms
75 1ms/step CE
825-618 FSK Monitor Timer Value G3M_FSK_CHK_TIMER
0
～ 255:0ms ～ 255ms
200 1ms/step CE
825-619 Image Info Send: delayed time ITUT_PIX_DELAY
0
～ 255:0ms ～ 2500ms
50 10ms/step CE
825-620
Image Info Receive Dropout
monitor timer value
G3M_DROP_OUT_TIMER
0
～ 255:0ms ～ 2500ms
100 10ms/step CE
825-621 NSF/DIS sending time G3M_NSF_DIS_TIME
0:3sec
1:3.45sec
2:2.55sec
3:4.5sec
0CE
825-622
Communication Mode (Speed)
at send
G3M_TX_MODEM_SPEED
0:Fall back from the max
capability of remote
terminal.
1:V27ter 2400
2:V27ter 2400,V27ter
4800
3:V27ter 2400,V27ter
4800,V29 7200,V29 9600
4:V27ter 2400,V27ter
4800,V29 7200,V29 9600
5:V27ter 2400,V27ter
4800,V29 7200,V29
9600,V17 7200,V17
9600,V17 12000,V17
14400
0CE
825-623
Communication Mode (Speed)
at receive
G3M_RX_MODEM_SPEED
0:V27ter+V29+V17
1:V27ter Fallback Mode
(2400 only)
2:V27ter(2400,4800)
3:V29(7200,9600)
4:V27ter+V29
5:V27ter+V29
0CE
825-625 DIS Ignorance Qty G3M_DIS_IGNORE_NO
0
～ 255: 0 to 255
0CE
825-626 TSI/CIG Sending Timing G3M_TSI_CIG_MODE
0:AUTO
1: Always send
2: Not send
0CE
825-627 Send CSI G3M_WITH_CSI
0: Send
1: Not send
0CE
825-628 FTT Qty before fallback G3M_FTT_FALLBACK
0: all 2FTT
2: all 1FTT
0CE
825-629 TCF Signal Criterion G3M_TCF_CHECK
0:1.2sec
1:1sec
0CE
825-630 Send Cable Equalizer G3M_TX_CABLE_EQU
0:0db(0km)
1:4db(1.9km)
2:8db(3.6km)
3:12db(7.2km)
0CE
Chain
-Link
Description Name Value Label
Default Details Access
OFF/
ON
