6 – 55
Chapter 6 General
825-084
External Tel Calling Frequency
ON
EX_RINGER_FREQ_ON_TIME
6250
～
65535:3125
μ
s
～
31250
μ
s
62500
0.5
μ
s/step
CE
825-085
External Tel Calling Frequency
OFF
EX_RINGER_FREQ_OFF_TIME
6250
～
65535:3125
μ
s
～
31250
μ
s
62500
0.5
μ
s/step
CE
825-086
External Tel Calling ON Time
T1
EX_RINGER_ON_T1
5
～
250:100ms
～
5000ms
20ms/step
50
Pseudo-ring Back Tone/External
Speaker Ringing Pattern ON
Time 1
CE
825-087
External Tel Calling OFF Time
T2
EX_RINGER_OFF_T2
5
～
250:100ms
～
5000ms
20ms/step
100
Pseudo-ring Back Tone/External
Speaker Ringing Pattern OFF
Time 1
CE
825-088
External Tel Calling ON Time
T3
EX_RINGER_ON_T3
5
～
250:100ms
～
5000ms
20ms/step
50
Pseudo-ring Back Tone/External
Speaker Ringing Pattern ON
Time 2
CE
825-089
External Tel Calling OFF Time
T4
EX_RINGER_OFF_T4
5
～
250:100ms
～
5000ms
20ms/step
100
Pseudo-ring Back Tone/External
Speaker Ringing Pattern OFF
Time 2
CE
825-090 Public Line Dial Tone Detection DIS_DIALTONE_PSTN
0: Detect
1: Not detect
1
Set whether to detect dial tone
with PSTN connected.
CE
825-092
The timing of starting sending
CED Signal at manual receiving
MANUAL_CED_START_TIME
0
～
255:0ms
～
25500ms
0 100ms/step CE
825-093
The timing of starting sending
CNG Signal
CNG_SEND_START_TIME
0
～
255:0ms
～
25500ms
30 100ms/step CE
825-094
The timing of starting sending
CNG at manual send
MANUAL_CNG_START_TIME
0
～
255:0ms
～
25500ms
0 100ms/step CE
825-096 Remote Receive REMOTE_RCV_MODE
0:OFF
1:ON
0USER
825-097 Remote Receive DTMF No. 1 REMOTE_RCV_DTMF1
0
～
9
0USER
825-098 Remote Receive DTMF No. 2 REMOTE_RCV_DTMF2
0
～
9
0USER
825-099 Ring ON Judge Time RING_ON_JUDGE
0
～
255 1ms/step
155 CE
825-100 Ring OFF Judge Time RING_OFF_JUDGE
0
～
255 10ms/step
120 CE
825-101
Time before deciding Ring is no
longer on the line.
RING_OFFMAX
0
～
255 100ms/step
55 CE
825-102 PrefixDial PREFIX_MODE
0: Not add
1: Add
0USER
825-103 PrefixDial Number1 PREFIX_NUM_1
NULL,'1','2','3,','4','5','6','7'
,'8','9','0','#','*'
0USER
825-104 PrefixDial Number2 PREFIX_NUM_2
NULL,'1','2','3,','4','5','6','7'
,'8','9','0','#','*'
0USER
825-105 PrefixDial Number3 PREFIX_NUM_3
NULL,'1','2','3,','4','5','6','7'
,'8','9','0','#','*'
0USER
825-106 PrefixDial Number4 PREFIX_NUM_4
NULL,'1','2','3,','4','5','6','7'
,'8','9','0','#','*'
0USER
825-107 PrefixDial Number5 PREFIX_NUM_5
NULL,'1','2','3,','4','5','6','7'
,'8','9','0','#','*'
0USER
825-108 SiDAA Manual Calibration SIDAA_MANUAL_CALIBRATION
0: Disable
1: Enable
0CE
825-110 Dial Tone Pattern Detection DIS_DIALTONE_PATTERN
0: Not detect
（
Detect by
detecting 800 or more
consecutive ms.)
1: Detect
0CE
825-111
Dial Tone ON/OFF Time: lower
limit
DIALTONE_ONOFFPTN_MIN
8
～
255 10ms/step
10 CE
825-112
Dial Tone ON/OFF Time: upper
limit
DIALTONE_ONOFFPTN_MAX
8
～
255 10ms/step
100 CE
825-201
NCU Country Setting Relay
Setting
NCU_COUNTRY_RELAY
0: Disable
1: Enable
0
Added for South Africa and
Mexico PTT Exam.
CE
825-202 FastEdgePulseDial2 DAA_REG732
0x00
～
0x02
0x00 DAA Register 732 setting CE
825-203
DAA SSD Register 0x02
Setting
DAA_REG_EMI
0x00
～
0xFF
0xFD CE
825-601 Line Monitor Setting LINE_MONITOR_ENABLE
0:OFF
1:ON
1USER
825-602 Line Monitor Volume LINE_MONITOR_VOLUME
0: Mute
1: low
2: medium
3: high
2USER
825-604 CED Detection Time CED_DETECT_TIMER
25
～
255:
25 20ms/step CE
Chain
-Link
Description Name Value Label
Default
Details Access
OFF/
ON
