6 – 54
Chapter 6 General
825-050 SiDAA Operation Mode DAA_MODE
0x00
～
0xFF
0x01: Reserve
0x02: Reserve
0x04: Check RING with
Line Monitor ON
0x08: Reserve
0x10: Reserve
0x20: Reserve
0x40: Reserve
0x80: Reserve
0x00
"OR" of each bit enables the use
of system data set by nation.
0x01
：
Reserve
0x02
：
Reserve
0x04
：
Decide to detect RING
when Line Monitor is ON.
0x08
：
Reserve
0x10
：
Reserve
0x20
：
Reserve
0x40
：
Reserve
0x80
：
Reserve
CE
825-054 OFF HOOK Threshold selection ONHOOK_LVS_THRESH_HI
0:Low
1:Medium
2:High
1
Selection of External Tel Hook
Status Detection Threshold
USER
825-060 DM Prevention function
UNWANTED_REMOTE_PREVENTI
ON
0: Prohibit
1: Permit
0USER
825-062 Dial Pulse Quantity NUM_DIAL_PULSE
0:N
1:10-N
2:N+1
0 DP Pulse Qty selection CE
825-063 PB Sending Time PB_TONE_TIME
0
～
255:0ms
～
255ms
1ms/step
100 PB (DTMF) Signal sending time CE
825-064 PB Pause Time PB_INTERDIGIT
0
～
255:0ms
～
255ms
1ms/step
120 PB minimum pause time CE
825-065
DTMF Sending Attenuation
Level
PB_ATT_LEVEL
4
～
15:-4dbm
～
-15dBm
6 DTMF Sending Level setting CE
825-066
DTMF difference between high-
pass and low-pass levels
PB_LEVEL_SUB
0:2.0dB
1:2.5dB
2:3.0dB
3:3.5dB
4:4.0dB
5:4.5dB
6:5.0dB
12:0dB
13:0.5dB
14:1.0dB
15:1.5dB
0
Set a level difference between
high-pass and low-pass
frequencies in PB (DTMF)
dialing.
Level difference
：
high-pass to
low-pass
CE
825-067 10PPS Make Time MAKE_10PPS
1
～
106:1ms
～
106ms
1ms/step
31 CE
825-068 10PPS Break Time BREAK_10PPS
1
～
106:1ms
～
106ms
1ms/step
67 CE
825-069 20PPS Make Time MAKE_20PPS
1
～
106:1ms
～
106ms
1ms/step
16 CE
825-070 20PPS Break Time BREAK_20PPS
1
～
106:1ms
～
106ms
1ms/step
34 CE
825-071 DP Interdigit Pause Time DP_INTERDIGIT
0
～
255:0ms
～
5110ms
20ms/step
36 CE
825-072 (4/0.1) Pause Time PAUSE_TIME
0
～
255:0ms
～
25500ms
100ms/step
40
Pause Time. When pause "-" is
pressed, allow this system-data-
specified time before dialing the
next dial data.
CE
825-073 Blind Dial Time BLIND_TIME
3
～
255:3s
～
255s
-- The setting range below
applies to South Africa
only.
1
～
255
：
1s
～
255s
3
With PBX connected, time from
when the line gets connected to
the start of dialing
(An increase of approx. 1.3 sec
from a setting value due to
modem restrictions
）
CE
825-074
Time to time out Dial Tone
Detection
TIME_TO_DETECT_DIALTONE
0
～
255:0s
～
255s
1S/step
20
Used as timeout when Dial Tone
cannot be detected.
CE
825-079 ONHOOK Detection Time ONHOOK_DETECT_TIME
10
～
255:200ms
～
5100ms
20ms/step
65
Time before deciding External
Tel is on hook when it is put on
hook.
CE
825-080
OFF HOOK detection time with
RING Signal not existing on the
line.
OFFHOOK_DETECT_TIME
15
～
255s:300ms
～
5100ms
20ms/step
15
Time before deciding External
Tel is off hook when it is taken
off hook with RING Signal not
having come.
CE
825-081
OFF HOOK detection time with
RING Signal existing on the line
OFFHOOK_DETECT_TIME_RING
15
～
255ms 300ms
～
5100ms
20ms/step
15
Time before deciding External
Tel is off hook when it is taken
off hook with RING Signal
coming.
CE
825-083 Ring Volume setting RINGER_VOLUME
0: Mute
1: low
2: medium
3: high
3USER
Chain
-Link
Description Name Value Label
Default
Details Access
OFF/
ON
