Fuji Xerox DocuPrint CM305 df Service Manual

6 – 53
Chapter 6 General
825-028 Busy Tone Frequency BUSYTONE_FREQ
0:400Hz
1:350Hz
～ 450Hz
2:300Hz
～ 500Hz
3:450Hz
～ 650Hz
4:245Hz
～ 650Hz
3
Busy Tone Detectable
Frequency setting
CE
825-029 Busy Tone Pattern BUSYTONE_PATTERN
0:ON/OFF 0.4
～ 0.6s
（ twice ）
1:ON/OFF 0.2 ～ 0.3s （ 4
times
） , ON/OFF 0.4 ～
0.6s （ twice ）
2:ON/OFF 0.2 ～ 0.3s （ 4
times
）
3:ON/OFF 0.12 ～ 0.44s
（ 3 times ）
4:ON/OFF 0.3 ～ 0.8s
（ twice ）
5:ON/OFF 0.2 ～ 0.6s
（ twice ）
6:ON/OFF 0.5 ～ 1s
（ twice ）
7:ON/OFF 0.12 ～ 1.2s
（ twice ）
8:ON 800 ～ 1.2S,OFF 3.2
～ 4.8s （ twice ）
1
Busy Tone Detectable Pattern
setting
CE
825-030
Permit/Prohibit Busy Tone
Detection when calling out
BUSYTONE_DETECTION
0
： Prohibit
1
： Permit
1 Busy Tone Detection setting CE
825-031 Resend Quantity NUMBER_OF_RESEND
0
～ 5: 0 to 5
1
Re-call out this system-data-
specified number of times when
any of the conditions is met.
【 Busy Tone Detection
"Prohibited"
】
・
An error has occurred during
FAX communication.
【 Busy Tone Detection
"Permitted"
】
・
An error has occurred during
FAX communication.
・ Over with no response from
the other party.
CE

825-032 Redial Quantity NUMBER_OF_REDIAL
0
～ 9: 0 to 9
3
Re-call out this system-data-
specified number of times when
any of the conditions is met.
【 Busy Tone Detection
"Prohibited"
】
・
Over with no response from
the other party.
【 Busy Tone Detection
"Permitted"
】
・
Over by detecting busy tone.
USER

825-033 Max Redial Quantity NUMBER_OF_REDIAL_MAX
0
～ 255: 0 to 255
14 CE
825-034 Redial Interval INTERVAL_OF_REDIAL
1
～ 15:1min ～ 15min
1USER

825-035 FAX Communication Interval COMM_INTERVAL
3
～ 255:3s ～ 255s
1S/step
8
Interval time between
independent communications.
There is always this system-
data-specified length of time
between one call-out and
another.
USER

825-036
Check the same destination to
re-call out
CAPAB_NUM_CHECK
0:OFF
1:ON
1CE
825-037
Interval between calls-out to the
same destination
NUM_CHECK_TIMER
1
～ 255:1s ～ 255s
60 CE
825-045 Ring Threshold DAA_REG730
0x00
～ 0xFF
0xE8 DAA Register 730 setting CE
825-046 Complex DAA_REG731
0x00
～ 0x02
0x02 DAA Register 731 setting CE
825-047 DCCurve DAA_REG733
0x00
～ 0x04
0x02 SiDAA Register 733 setting CE
825-048 Rmake DAA_REG734
0x00
～ 0xFF
0x01 SiDAA Register 734 setting CE
825-049 FastEdgePulseDial DAA_REG74F
0x00
～ 0x01
0x01 SiDAA Register 74F setting CE
Chain
-Link
Description Name Value Label
Default Details Access
OFF/
ON
