6 – 74
Chapter 6 General
- DTMF Send
Unplug the modular connector of the telephone line before performing this test.
Otherwise, a call will be made to the relevant number.
- DTMF Continuous
Checks the tone output for all touch tones for tone dialing. Below are the touch tones:
DTMF: 0/1/2/3/4/5/6/7/8/9/A/B/C/D//#
- DTMF Individually
Checks the tone output for one of the 16 key numbers set on the LCD.
- Dial Pulse Send
Unplug the modular connector of the telephone line before performing this test.
Otherwise, a call will be made to the relevant number.
-DP10 Individually
Checks the 10PPS pulse output for one of the 10 key numbers set on the LCD.
-DP20 Individually
Checks the 20PPS pulse output for one of the 10 key numbers set on the LCD.
- Ring Back Tone
Checks the tone output for the ring back tone.
- Data Send
Checks the modem output for each of the transmission rates in compliance with ITU-T recommendations.
Below are the data sending patterns:
All 0/All 1/0101010101/0000100001/11101110
- Line Voltage
The voltage displayed in this test varies from country to country. (For instance,
normally 48V in the United States)
Measures the telephone line voltage.
- Line Current
20mA is the minimum guaranteed current in the United States.
Measures the telephone line amperage.
V.34 (bps)
36600/31200/28800/26400/24000/21600/19200/16800/
14400/12000/9600/7200/4800/2400
V.29 (bps) 9600/7200
V.27ter (bps) 4800/2400
V.21 (bps) 300
V.17 (bps) 14400/12000/9600/7200
