6 – 75
Chapter 6 General
(3) Information
- Scan Counter
The value of scan count is displayed. FB: Scanning of platen mode/ADF: Scanning of ADF mode.
(4) Scanner Maintenance
- White Balance
Enables automatic calibration of the correction value for platen scanning (FB) and ADF scanning
(ADF).
- Shading Parameter
Adjusts the white balance value read from the white reference plate.
Coeff: White reference plate value after shading correction.
Target: Target value of Coeff.
Do not change this setting; the image quality may be affected.
- Registration Param.
Adjusts the side and lead registrations during document scanning.
Do not change this setting; the image quality may be affected.
- Auto Registration
Sets whether or not to auto-adjust the registration.
- Sensor Parameter
Adjusts the Feed sensor output value.
- Vertical Scan Mag.
Adjusts the scaling in the sub-scanning direction.
Do not change this setting; the image quality may be affected.
- Test Pattern
Performs to select Test Pattern and to set the parameter.
* The beginning "*" of the value suggests to complete setting.
Pt No. Contents Value
Pattern No. Value (Dec) *000
07 Step Cycle Value (Hex) *FFFF
08 Step Cycle Value (Hex) *FFFF
