7 - 27
Chapter 7 Wiring Data
Signal line name Description
CLOCK
DATA
Control signal of the PWBA EEPROM
CLOCK
DATA
Control signal of the EEPROM PHD
TEMP SNS
Temperature data in the printer by the SENSOR HUM
(Analog value)
HUM SNS
Humidity data in the printer by the SENSOR HUM
(Analog value)
ERASE K ON (L) +3.3VDC
ERASE Y/M/C ON (L) +3.3VDC
ON/OFF signal of the LED ASSY ERASE
ADC SENSOR
Toner patch density data measured by the ADC SENSOR
(Analog value)
LED REM Remote signal of the LED of ADC SENSOR
ADC V MONI Control signal of the ADC SENSOR
