Fuji Xerox DocuPrint CM305 df Service Manual

7 - 28
Chapter 7 Wiring Data
7.5.2.6 HIGH VOLTAGE
PWBA MCU
PL8.3.6
PHD ASSY
PL4.1.21
P/J16
1
2
3
4
5
6
7
8
PWBA HVPS
PL4.1.19
HARN ASSY HVPS AIO
PL9.1.5
P/J161
CF
DB-K
TR-K
TR-C
TR-M
TR-Y
BCR
BTR
BTR : Bias Transfer Roll
BCR : Bias Charge Roll
Developer
DB-C
DB-M
DB-Y
10
9
8
7
6
5
4
3
TR MON
NC
HV DO
HV LD
HV CLK
+3.0V REF
SG
9
10
2
1
MAIN CLK
SG
I/L +24V
MiA07008KA
K
C
M
Y
+3.0V REF
