Operation Manual – DLDP

H3C S3100 Series Ethernet Switches Chapter 1 DLDP Configuration

1-13

II. Network diagram

SwitchB

SwitchA

GE1/1/1

SwitchB

SwitchA

SwitchB

SwitchA

SwitchB

SwitchA

GE1/1/1

GE1/1/2

Figure 1-3 Network diagram for DLDP configuration

III. Configuration procedure

1) Configure Switch A

# Configure the ports to work in mandatory full duplex mode at a rate of 1,000 Mbps.

<SwitchA> system-view

[SwitchA] interface gigabitethernet 1/1/1

[SwitchA-GigabitEthernet1/1/1] duplex full

[SwitchA-GigabitEthernet1/1/1] speed 1000

[SwitchA-GigabitEthernet1/1/1] quit

[SwitchA] interface gigabitethernet 1/1/2

[SwitchA-GigabitEthernet1/1/2] duplex full

[SwitchA-GigabitEthernet1/1/2] speed 1000

[SwitchA-GigabitEthernet1/1/2] quit

# Enable DLDP globally.

[SwitchA] dldp enable

# Set the interval for sending DLDP packets to 15 seconds.

[SwitchA] dldp interval 15

# Configure DLDP to work in enhanced mode.

[SwitchA] dldp work-mode enhance

# Set the DLDP handling mode for unidirectional links to auto.

[SwitchA] dldp unidirectional-shutdown auto

# Display the DLDP state.

[SwitchA] display dldp 1
