Operation Manual – VLAN-VPN
H3C S3100 Series Ethernet Switches Chapter 3
VLAN Mapping Configuration
3-6
# As Ethernet 1/0/11 of Switch A not only receives packets of the customer VLAN but
also forward packets from the service provider network, you need to configure the port
as a trunk port or hybrid port. In the following part, configure Ethernet 1/0/11 as a hybrid
port and configure the port to permit the packets of VLAN 100 and VLAN 500 to pass
through with VLAN tags.
[SwitchA] interface Ethernet 1/0/11
[SwitchA-Ethernet1/0/11] port link-type hybrid
[SwitchA-Ethernet1/0/11] port hybrid vlan 100 tagged
[SwitchA-Ethernet1/0/11] port hybrid vlan 500 tagged
[SwitchA-Ethernet1/0/11] quit
# Add Ethernet 1/0/12 to VLAN 200 and VLAN 600 in the same way.
[SwitchA] interface Ethernet 1/0/12
[SwitchA-Ethernet1/0/12] port link-type hybrid
[SwitchA-Ethernet1/0/12] port hybrid vlan 200 tagged
[SwitchA-Ethernet1/0/12] port hybrid vlan 600 tagged
[SwitchA-Ethernet1/0/12] quit
 Note:
z If you configure Ethernet 1/0/11 and Ethernet 1/0/12 as trunk ports, you also need to
add the two ports to the corresponding customer VLANs and service VLANs.
z In the above example, VLAN 1 is the default VLAN and permitted to pass through all
the ports by default. If you have changed default VLAN of a port, you need to
configure the port to permit the default VLAN to pass through.
# Configure Ethernet 1/0/10 of Switch A as a trunk port capable of transmitting packets
of VLAN 500 and VLAN 600.
[SwitchA] interface Ethernet 1/0/10
[SwitchA-Ethernet1/0/10] port link-type trunk
[SwitchA-Ethernet1/0/10] port trunk permit vlan 500 600
[SwitchA-Ethernet1/0/10] quit
# Define a VLAN mapping rule on Ethernet 1/0/11 that maps VLAN 100 to VLAN 500
and enable the VLAN mapping function on Ethernet 1/0/11.
[SwitchA] interface Ethernet 1/0/11
[SwitchA-Ethernet1/0/11] vlan-mapping vlan 100 remark 500
[SwitchA-Ethernet1/0/11] quit
# Define a VLAN mapping rule on Ethernet 1/0/12 that maps VLAN 200 to VLAN 600
and enable the VLAN mapping function on Ethernet 1/0/12.
[SwitchA] interface Ethernet 1/0/12
