Chapter 3 ’Web User Graphical Interface’ — Operating Instructions (Tutorial)
Electra VS - Version 05.10 123
User Manual - Rev. A
Figure 3-61. Statmux tab - Consult mode
List of
MPTS
with
statmux
Stamux parameters for each VBR program in the selected MPTS:
• Name of the job included in the statistical multiplexing
• PID of the video component
• Minimum bitrate of the video component, in bits per second
• Maximum bitrate of the video component, in bits per second
• Quality of the video component, in percentage (set 90 for the
maximum quality)
• Fallback bitrate, in bits per second: this is the bitrate used if the
communication is lost between the allocator and the encoder.
This is not configurable, the value is automatically computed by
the equipment.
• State of the job
• Status of the job
Parameters of the selected MPTS
Selected MPTS
