Chapter 3 ’Web User Graphical Interface’ — Operating Instructions (Tutorial)
90 Electra VS
-
Version 05.10
User Manual - Rev. A
Sorting Elements in Arrays
In any array, you can sort elements by any column. To do so, click the
header column once. A white arrow appears in this header.
To change the sorting mode, click the header once more. When sorted in
increasing order, the arrow is displayed. In decreasing order, the
arrow is shown.
Moving and Docking
Each view can be moved by dragging and dropping its title bar. You can
also move a view to drag the view over the left, right, top, or bottom
border of another view or on a new independent window.
Commonly Used Elements
Some elements are recurrent in the GUI, as pictograms for instance.
These elements are described here.
Status Pictograms
Table 3 -1
lists the status pictograms used in the GUI.
Table 3-1. Status pictograms
Status icon Meaning
OK
Information message
Warning
Minor error
Major error
Critical error
