Harmonic ELECTRA VS - Electra VS 10 RU (AC JPN Triple Phase @ 200 VAC)

Appendix A ’Technical Specifications’ — Hardware Delivery Specifications
494 Electra VS - Version 05.10
User Manual - Rev. A
Electra VS 10RU (AC JPN Triple Phase @ 200VAC)
Electra VS 10RU fitted with 16 system storage and processing blades
Table A-31. Electra VS G7 10RU fitted with 16 blades (AC JPN Triple Phase @ 200VAC),
Electrical and Thermal specifications
Idle
@100%
Utilization
Circuit
Max
Total system Inrush
Current
per Branch
---------------- < 210A @ 200V, < 2ms ----------------------------
Total Input Power (W) 2256 4376 5390
Total Input VA 2302 4465 5500
Total Input Current (A)t 6.64 12.89 15.88
Input Current per cord
(A)
3.322 6.445 7.938
Total Airflow (CFM) 179 348 554
Total Airflow (CMM) 510 16
Heat Dissipating
Power (BTU)
7691 14921 18379
Table A-32. Electra VS G8 10RU fitted with 16 blades (AC JPN Triple Phase @ 200VAC),
Electrical and Thermal specifications
Idle
@100%
Utilization
Circuit
Max
Total system Inrush
Current
per Branch
---------------- < 210A @ 200V, < 2ms ----------------------------
Total Input Power (W) 1678 5071 6348
Total Input VA 1712 5174 6478
Total Input Current (A)t 4.94 14.94 18.70
Input Current per cord
(A)
2.471 7.468 9.349
Total Airflow (CFM) 133 388 630
Total Airflow (CMM) 411 18
Heat Dissipating
Power (BTU)
5721 17291 21647
