Appendix F ’Network Settings’ — Hardware Delivery - 6RU and 10RU devices
580 Electra VS - Version 05.10
User Manual - Rev. A
An internal data LAN must not be shared on several blade centers: each
blade center must have its own
internal data LAN.
Interface Bitrates
You may adjust the bitrates for the interfaces.
Bitrate Allocation on 10RU Interfaces
You may adjust the bitrates of the four interfaces, for a total of 10 Gb/s.
The factory configuration is as follows:
 Interface 1: 2 Gb/s
 Interface 2: 3 Gb/s
 Interface 3: 1 Gb/s
 Interface 4: 4 Gb/s
Bitrate Allocation on 6RU Interfaces
You may adjust the bitrates of the eight interfaces, for a total of 20 Gb/s.
The factory configuration is as follows:
 Interface 1: 2 Gb/s
 Interface 2: 3 Gb/s
 Interface 3: 1 Gb/s
 Interface 4: 2.4 Gb/s
 Interface 5: 3.5 Gb/s
 Interface 6: 2.3 Gb/s
Table 1. ‘Linking 10RU or 6RU blade centers via an external switch’ diagram key
Item Description
1 and 2 Link between switch 1 and switch 2
3 Enclosure 1 (10RU)
4 Enclosure 2 (10RU)
5 Enclosure 3 (10RU)
6 Enclosure 4 (10RU)
8 Link to switch 2
9 Internal Dual 10Gb Stacking links
